This is in practically like new condition, with no marks, dings, nicks, sleeks, or scratches on it. It comes in its original box with manual.
The Baader Stronghold Tangent Mount Assembly is a very compact but stiff two-dimensional head, with micro adjustments which can hold a maximum load of up to 7 kg. It allows precise stable adjustment for guiding.
The Baader Planetarium Stronghold Tangent Mount Assembly is used for guiding scopes, viewfinders, and telephoto lenses as a piggy-back mounting system. The Stronghold Tangent Assembly is very compact but with a stiff, two-dimensional head with micro adjustments which can hold a max load of up to 7 kg. Whether you want to fix a guidescope to the main telescope or attach viewfinders to the existing telescope, the Stronghold Tangent Mount Assembly makes it possible to do so.
The Top panel has a 1/4" screw nad 6St M6 threaded hole, with a recommended thread depth of 6mm. Included in the Stronghold Tangent Mount Assembly base plate is a 3/8" to 1/4" photo thread, 1/4" photo screw for camera/spotting scope attachment, EQ (Orion type) / GP (Vixen Great Polaris) dovetail clamp, and an additional lever for firm screw tension.
Stronghold Tangent Mount Assembly Specifications
- Color: Black
- Weight: 680g
- Material: Aluminum, hard anodized
- Loading Capacity: 7kg
- Azimuth Adjustment: /- 23-deg, elevation: /- 35-deg
- Length: 115mm (knobs included)
- Width: 128mm (knobs included)
- Height: 54mm (without EQ clamp)
- Mounting Options for Top: 1/4" photo thread, 6pc. M6 threads
- Mounting Options for Base Plate: 1/4" and 3/8" photo threads, 4pc. M6 and 4pc. M5 threads
- General Mounting: EQ-clamp (Vixen Standard) included, can be mounted on top or on base
